Pressure Reducing Valves Gunmetal & Stainless Steel with Flange Connection

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN15

IMPA 756544 PCE

Gunmetal pressure reducer, DN15, PN40 with DIN EN 1092-3 flange connection, adjustable secondary pressure 0.5–15 bar, built-in dirt trap and pressure gauge ports G 1/4". Low pressure model with EPDM seal for water and neutral gases. ABS, BV, GL and LR type approvals held.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN15

IMPA 756545 PCE

Gunmetal flanged pressure reducing valve DN15, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS REDUCING W/FLANGE, PN40 GUNMETAL 682MGFO-SP DN100

IMPA 756546 PCE

Gunmetal flanged pressure reducing valve DN100, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN15

IMPA 756547 PCE

Gunmetal flanged pressure reducing valve DN15, PN40, high pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-HP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN15

IMPA 756548 PCE

Stainless steel flanged pressure reducing valve DN15, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN15

IMPA 756549 PCE

Stainless steel flanged pressure reducing valve DN15, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-HP DN15

IMPA 756550 PCE

Stainless steel flanged pressure reducing valve DN15, PN40, high pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN16 S.STEEL #482MGFO-SP DN65

IMPA 756551 PCE

Stainless steel flanged pressure reducing valve DN65, PN16, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN65

IMPA 756552 PCE

Stainless steel flanged pressure reducing valve DN65, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN80

IMPA 756553 PCE

Stainless steel flanged pressure reducing valve DN80, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN20

IMPA 756554 PCE

Gunmetal flanged pressure reducing valve DN20, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-LP available.

VALVE PRESS REDUCING W/FLANGE, PN16 GUNMETAL #682MGFO-SP DN65

IMPA 756555 PCE

Gunmetal flanged pressure reducing valve DN65, PN16, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS REDUCING W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN65

IMPA 756556 PCE

Gunmetal flanged pressure reducing valve DN65, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS REDUCING W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN80

IMPA 756557 PCE

Gunmetal flanged pressure reducing valve DN80, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN25

IMPA 756558 PCE

Gunmetal flanged pressure reducing valve DN25, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-LP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN32

IMPA 756559 PCE

Gunmetal flanged pressure reducing valve DN32, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-LP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN40

IMPA 756560 PCE

Gunmetal flanged pressure reducing valve DN40, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-LP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-LP DN50

IMPA 756567 PCE

Gunmetal flanged pressure reducing valve DN50, PN40, low pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-LP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN20

IMPA 756568 PCE

Gunmetal flanged pressure reducing valve DN20, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN25

IMPA 756569 PCE

Gunmetal flanged pressure reducing valve DN25, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN32

IMPA 756570 PCE

Gunmetal flanged pressure reducing valve DN32, PN40, standard pressure rating 0.5–15 bar outlet. Single seal design with integral sediment trap; adjustable via non-rising stem. Gauge port G 1/4". EPDM seals for water/neutral fluids; FKM option for oils/fuels. DIN EN 1092-3 flange. Primary to 30 bar. ABS/BV/GL/LR type-approved. Stainless steel version 482mGFO-SP available.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN40

IMPA 756576 PCE

Gunmetal flanged pressure reducing valve DN40, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-SP DN50

IMPA 756577 PCE

Gunmetal flanged pressure reducing valve DN50, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN20

IMPA 756578 PCE

Gunmetal flanged pressure reducing valve DN20, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN25

IMPA 756579 PCE

Gunmetal flanged pressure reducing valve DN25, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN32

IMPA 756580 PCE

Gunmetal flanged pressure reducing valve DN32, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN40

IMPA 756581 PCE

Gunmetal flanged pressure reducing valve DN40, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 GUNMETAL #682MGFO-HP DN50

IMPA 756582 PCE

Gunmetal flanged pressure reducing valve DN50, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN20

IMPA 756583 PCE

Stainless steel flanged pressure reducing valve DN20, PN40, low-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN25

IMPA 756584 PCE

Stainless steel flanged pressure reducing valve DN25, PN40, low-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN32

IMPA 756585 PCE

Stainless steel flanged pressure reducing valve DN32, PN40, low-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN40

IMPA 756586 PCE

Stainless steel flanged pressure reducing valve DN40, PN40, low-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-LP DN50

IMPA 756587 PCE

Stainless steel flanged pressure reducing valve DN50, PN40, low-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN20

IMPA 756588 PCE

Stainless steel flanged pressure reducing valve DN20, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN25

IMPA 756599 PCE

Stainless steel flanged pressure reducing valve DN25, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN32

IMPA 756600 PCE

Stainless steel flanged pressure reducing valve DN32, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN40

IMPA 756612 PCE

Stainless steel flanged pressure reducing valve DN40, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-SP DN50

IMPA 756613 PCE

Stainless steel flanged pressure reducing valve DN50, PN40, standard pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-HP DN20

IMPA 756614 PCE

Stainless steel flanged pressure reducing valve DN20, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.

VALVE PRESS. REDUCE W/FLANGE, PN40 S.STEEL #482MGFO-HP DN25

IMPA 756623 PCE

Stainless steel flanged pressure reducing valve DN25, PN40, high-pressure range 0.5–15 bar outlet. Single seal with integral strainer, adjustable via non-rising stem; DIN EN 1092-3 flange, G 1/4" gauge port. ABS/BV/GL/LR approved. Available with EPDM (water, neutral liquids, air) or FKM (oils, fuels) seals.
